كود المنتج:
DR-30XM
30 Buttons Audio Outdoor Aluminum Slave Panel
30 Buttons Audio Outdoor Aluminum Slave Panel (DR-30XM) من منتجات انتركم صوتي. راجع المواصفات الفنية وبيانات المنتج لاختيار الحل المناسب، ومتوفر من دو لينك مصر للفنيين والشركات والمشروعات.
DR-30XM
The Commax DR-30XM is a 30-button audio intercom lobby phone, or extension panel, for multi-unit buildings. It is part of the DR-XM series, which includes panels for different numbers of apartments. The DR-30XM features a metal design with a wide nameplate and connects with specific Commax residential intercom systems.
Features
- Capacity: The panel includes 30 buttons, designed for calling individual units in a building with up to 30 apartments.
- Functionality: Allows visitors to make house calls and talk to residents through a "call and talk" function.
- Design: It has a durable metal construction and a wide name plate to display resident names clearly.
- Indicators: An LED light provides visual indication.
- Compatibility: It is compatible with a range of Commax residential intercom systems, including DP-SS, DP-RS, and DP-ML models.
- Wiring: Like other panels in the series, it uses a 3-common-wire setup plus one individual wire for each unit.
- Power source: It requires DC 12V power.
- Installation: The panel is designed for flush mounting.
System integration
The DR-30XM panel can be used as an extension unit alongside a master panel to increase the number of available call buttons. For example, according to lcdtcorp.com, it can be used as an extension board with the DR-24ML. It integrates into a larger intercom network to provide full coverage for multi-household applications.
